1928405524

Manufacturer	Bosch
Packing unit	500pcs
Product Type	Connector Housing
Number of positions	3
Code	1
Blade width	2.8mm
Connection System	Wire-to-Device
Gender	Female
Sealed connection	Yes
Primary Locking (Terminal)	Lance-locking
Colour	black
Body Material	PA 66 GF
Length	28.1mm
Width	20.55mm
Height	30.6mm
Vibration Resistance	Engine / Transmission
Temperature range, min.	-40°
Temperature range, max.	150°
Terminal Sealing	Single wire seal
Type of seal (connector)	radial seal
Type of seal (cable)	single wire seal
Type of locking mechanism (connector)	with a connector position assurance
Secondary locking	Yes
Additional features	secondary lock blue
RoHS	Yes
