| TE | 151-02964 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals Application More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to RCD-CT-INSERT Competences Ratchet P-Clamp for mounting cables and hoses Cable holder Accessories Similar products |
| 描述 | Soft inserts (for A - D Series) for an additional level of protection Torque support for defined contact pressure Use of manual processing Tool EVO possible CT-Insert offers low fire hazard CT-Insert conform to low smoke generation requirements (UL94 V0) CT-Insert offers low evolution of toxic gases and corrosive acids in event of an fire |
| Colour | Black (BK) |
| Pack Cont. | 320 |
| Package Quantity per | bag |
| PART DESCRIPTION | RCD-CT-INSERT-PA666V0-BK |
| Product Family | Protection Inserts |
| Product Group | Ratchet P-Clamp Accessories |
| 颜色 | Black (BK) |
| Variant | Fixing clamp |
| Bundle ∅ max. | 47.0mm |
| Bundle ∅ min. | 34.0mm |
| Width (W) | 34.9mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V0 |
| Hazardous good | No |
| Material | Polyamide 6.6 + Polyamide 6 V0 (PA66/6V0) |
| Operating Temperature - °C | -40 °C to +85 °C |
| Specifications | EN 45545-2 |
| GTIN-13 / EAN | 4031026625584.0 |
| Packaging 1 - Height (m) | 0.15m |
| Packaging 1 - Length (m) | 0.395m |
| Packaging 1 - Qty | 320.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.02666m³ |
| Packaging 1 - Weight (kg) | 1.482255kg |
| Packaging 1 - Width (m) | 0.45m |
