| TE | 156-00036 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to T50ROC1A Competences Cable holder Accessories |
| 描述 | For post-installation of additional cables for preassembled cable looms Variety of twist angles and even different loop directions provide flexibility for cable routing For OC1 and 2A additional cable tie dimensions are available CBTO-series for cable ties up to 5 mm |
| Application Tool | MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO9 |
| Colour | Black (BK) |
| Identification Plate Position | none |
| Pack Cont. | 500pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | T50ROC1A-PA66HS/PA66HIRHS-BK |
| Product Group | 2-piece fixing ties with pipe clip |
| Short Description | 2-Piece fixing tie 202x4.6 mm, with pipe clip, PA66HS/PA66HIRHS, black |
| 颜色 | Black (BK) |
| Bundle ∅ max. | 45.0mm |
| Bundle ∅ min. | 4.0mm |
| Length (L) | 202mm |
| Min.Tensile Strength | 225N |
| Thickness (T) | 1.2mm |
| Width (W) | 4.6mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous good | No |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Operating Temperature - °C | -40 °C to +105 °C |
| GTIN-13 / EAN | 4031026252872.0 |
| Packaging 1 - Height (m) | 0.2m |
| Packaging 1 - Length (m) | 0.395m |
| Packaging 1 - Qty | 500.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.03555m³ |
| Packaging 1 - Weight (kg) | 1.414135kg |
| Packaging 1 - Width (m) | 0.45m |
