| TE | 150-48397 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals Application More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to T80RFT6X12 Competences Cable holder Accessories Similar products |
| 描述 | Easy to assemble without the need for a tool Cable tie head always situated in defined position Arrowhead simply locks into place Supporting legs provide a secure and firm fixing in areas where space is limited Versions for oval holes feature anti-twist protection |
| Application Tool | MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK9P, MK20, MK21, EVO7, EVO7SP, EVO9, EVO9HT |
| Colour | Grey (GY) |
| Identification Plate Position | none |
| Pack Cont. | 1000pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | T80RFT6X12-PA46-GY |
| Product Family | 1-piece fixing ties with arrowhead, with wings, for oval holes |
| Product Group | 1-Piece Fixing Ties with Arrowhead, with Wings, for Oval Holes |
| Releasable Closure (Yes/No) | No |
| Short Description | 1-Piece Fixing Tie with Arrowhead and Wings for Oval Holes PA46 228x4.6 grey |
| 颜色 | Grey (GY) |
| Tie Closure | plastic pawl |
| Variant | Inside Serrated |
| Bundle ∅ max. | 45.0mm |
| Bundle ∅ min. | 1.5mm |
| Length (L) | 228mm |
| Min.Tensile Strength | 222N |
| Width (W) | 4.6mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V2, Limited Fire Hazard, halogen free, low smoke generation, low generation of toxic gases and corrosive acid |
| Hazardous good | No |
| Material | Polyamide 4.6 (PA46) |
| Operating Temperature - °C | -40 °C to +130 °C, (+150 °C, 5000 h; +195 °C, 500 h) |
| GTIN-13 / EAN | 4031026121178.0 |
| Packaging 1 - Height (m) | 0.15m |
| Packaging 1 - Length (m) | 0.47m |
| Packaging 1 - Qty | 1000.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.03842m³ |
| Packaging 1 - Weight (kg) | 2.371597kg |
| Packaging 1 - Width (m) | 0.545m |
