| TE | 151-03109 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to EC39 Competences Cable holder Ratchet P-Clamp for mounting cables and hoses Similar products |
| 描述 | Clips to be pushed onto an edge Low-vibration routing of bigger bundle diameters To be closed single handed, a snap can be felt Bundels can be released at any time Covers are releasable for maintenance or post-installations EC27 and HCEC3.0SP-C: fixing element enables use of smaller bundle diameters EC41: for parallel guidance of two bundles HCEC3.0TPS: specially rounded surface to minimise risk of injury |
| Colour | Black (BK) |
| Pack Cont. | 100pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | EC39-PA66HIR-BK |
| Product Family | EdgeClip EC39 |
| Product Group | Fixing Elements for Tubes and Harnesses, for Edges |
| 颜色 | Black (BK) |
| Bundle ∅ max. | 15.9mm |
| Bundle ∅ min. | 15.3mm |
| Width (W) | 13.2mm |
| Flammability | UL 94 HB |
| Material | Polyamide 6.6, high impact modified (PA66HIR) |
| Operating Temperature - °C | -40 °C to +80 °C, (+105 °C, 500 h) |
| GTIN-13 / EAN | 7890176090133.0 |
