| TE | 151-00121 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals Application More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to RA13 Competences Cable holder Ratchet P-Clamp for mounting cables and hoses Similar products |
| 描述 | One-piece self adhesive mount for quick and easy installation Can be used without cable ties offering process optimization Designed to hold wires, cables or hoses Different sizes for various bundle diameters available Two types of adhesive can be offered |
| Colour | Black (BK) |
| Pack Cont. | 100pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | RA13-PA66-BK |
| Product Family | RA-Series |
| Product Group | Mounts with cable clip, self-adhesive |
| Short Description | Self Adhesive Clip with round design 25x25 mm black |
| 颜色 | Black (BK) |
| Variant | Closed |
| Bundle ∅ max. | 13.0mm |
| Length (L) | 25.0mm |
| Width (W) | 25.0mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V2 (excluding adhesive) |
| Hazardous good | No |
| Material | Polyamide 6.6 (PA66) |
| Operating Temperature - °C | -40 °C to +85 °C |
| GTIN-13 / EAN | 5022660314407.0 |
| Packaging 1 - Height (m) | 0.071m |
| Packaging 1 - Length (m) | 0.17m |
| Packaging 1 - Qty | 100.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0021m³ |
| Packaging 1 - Weight (kg) | 0.244029kg |
| Packaging 1 - Width (m) | 0.174m |
