| TE | 156-00128 |
| 分类 | 紧固件 |
| 品牌 | 海尔曼太通全球(HellermannTyton) |
| 类型 | Features Certifications & Approvals More products in this product group Base Data Product Dimensions Material and Specifications Logistics and Packaging More Information Further information to T50SMVCOC10-14 Competences Cable holder Accessories |
| 描述 | Clips offer an easy securing option when cable ties can’t be used. Clips are reusable, making relocation or adjustments simple. Clips can be attached to the panel prior to installing the pipe or hose. Bundle can rotate to any orientation, allowing routing in any direction regardless of mounting point. All-in-one bundling and mounting solution reduces costs. |
| Application Tool | MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO9 |
| Colour | Black (BK) |
| Identification Plate Position | none |
| Pack Cont. | 500pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | T50SMVCOC10-14-PA66HS/PA66HIRHS-BK |
| Product Group | 2-piece fixing ties with pipe clip |
| 颜色 | Black (BK) |
| Bundle ∅ max. | 50.0mm |
| Bundle ∅ min. | 2.0mm |
| Length (L) | 210mm |
| Min.Tensile Strength | 222N |
| Width (W) | 4.7mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous good | No |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Operating Temperature - °C | -40 °C to +105 °C |
| GTIN-13 / EAN | 4031026262550.0 |
| Packaging 1 - Height (m) | 0.39m |
| Packaging 1 - Length (m) | 0.47m |
| Packaging 1 - Qty | 500.0 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0999m³ |
| Packaging 1 - Weight (kg) | 1.593597kg |
| Packaging 1 - Width (m) | 0.545m |
