1928404927

Manufacturer	Bosch
Packing unit	81pcs
Product Type	Contact Housing
Number of positions	96
Code	A
Blade width	1.2mm
Connection System	Wire-to-Device
Gender	Female
Sealed connection	Yes
Primary Locking (Terminal)	Lance-locking
Colour	black
Body Material	PA 66 GF 30
Length	122.5mm
Width	41.8mm
Height	36.9mm
Vibration Resistance	Car body
Vibration strength	7G
Temperature range, min.	-40°
Temperature range, max.	125°
Terminal Sealing	Silicon gel seal
Type of seal (connector)	radial seal
Type of seal (cable)	silicone gel-seal for Matrix 1.2
Type of locking mechanism (connector)	lever and locking slide
Secondary locking	sliding pin
